Insulator Stable Dimension Epoxy Resin APG & Casting Process

Brand Name : wenyou

Model Number : 8217F

Certification : ISO9001, ISO14001, SGS, and UL

Place of Origin : China

MOQ : 20kg/pail as sample

Price : Negotiable

Payment Terms : Normally T/T, L/C

Supply Ability : Plenty of raw material in stock

Delivery Time : 7 -10 work days

Packaging Details : 20kg/pail, 220kg/barrel, 1200kg/tank

Classification : Double Components Adhesives

Usage : insulators, transformers, and other insulation products

Application : Electrical insulators for medium and high voltage applications

Appearance of epoxy resin : Transparent viscous liquid

Viscosity at 25°C : 3000 - 6000mPa.s

Density at 25°C : 1.16 - 1.20g/cm3

Vapor Pressure at 25°C : < 0.01Pa

Flash point : around 135°C

Discription : Insulator stable dimension epoxy resin APG & casting process resina epoxi

Contact Now

Brief Introduction



Insulator stable dimension epoxy resin APG & casting process resina epoxi

LE-8217F is a modified BPA (bisphenol A) type epoxy resin.
LH-8217F is a liquid modified carboxylic anhydride hardener.



Applications



Electrical insulators for medium and high voltage applications, such as insulators, transformers, and other insulation products.



Processing Methods



Conventional gravity casting process under vacuum.
Automatic pressure gelation process (APG).
Production process is adjustable according to client’s present production methods.



Properties



Two-component saturated cyclic epoxy resin system without pre-mixed fillers, liquid at room temperature.
Low curing shrinkage, good dimensional stability of the parts, excellent processing performance, and superior mechanical and electrical properties.


Formulation



Epoxy resin LE-8217F 100 pbw
Hardener LH-8217F 100 pbw
Filler Silica powder 300 - 350 pbw
Color paste LC series * 3 pbw



Advantage



Insulator Stable Dimension Epoxy Resin APG & Casting Process



Package Image



Insulator Stable Dimension Epoxy Resin APG & Casting Process

Shipment image



Insulator Stable Dimension Epoxy Resin APG & Casting Process



Example application image



Insulator Stable Dimension Epoxy Resin APG & Casting Process
